Technical Specifications
Surface Treatment
Painting/Galvanized
Dimensions
100 Sqm to 100000 Sqm
Cladding System
EPS /PU/Fiber Glass Wool Sandwich /Steel Panel
Door and Window
PVC or Aluminum Alloy; Sliding Door or Rolled Door
Ventilation
Ventilation Building/Unpowered Ventilator
Drawing Design
Auto CAD, Pkpm, Mts, 3D3s..
Structure Usage
Up to 50 Years
Production Capacity
5000t/Month
Earthquake-resistance
8 Grades
📊
Operational Scale: 486 staff members including 40 engineers and 12 professional designers.
Production: Monthly output reaches 5000 Tons within a 50,000+ sqm facility.
Structural System Details
| Item |
Specification |
| Main Steel Frame |
Column |
Q235, Q345 Welded H Section Steel |
| Beam |
Q235, Q345 Welded H Section Steel |
| Secondary Frame |
Purlin |
Q235 C and Z purlin |
| Tie Rod |
Q235 Circular Steel Pipe |
| Brace |
Q235 Round Bar |
| Support |
Q235 Angle Steel, Round Bar or Steel Pipe |
| Maintenance |
Roof/Wall Panel |
EPS / Glass Fiber / Rock Wool / PU Sandwich Panel; Steel Sheet |
| Accessories |
Windows/Doors |
Aluminium Alloy/PVC; Sliding Sandwich or Rolling Metal Doors |
| Wind Resistance |
12 Grades |
| Finish Options |
Alkyd painting (primary + finish) or Galvanized |
Global Project Experience
- Industrial Warehouse (13000 M2) - Argentina
- Warehouse (14000 M2) - Uzbekistan
- Workshop (12000 M2) - Canada
- Roof Truss (10000 M2) - Congo
- Vegetable Market (2500 M2) - Mauritius
- Pig Shed (3500 M2) - USA
- Chicken Shed (2800 M2) - Australia
- Aircraft Hangar (1300 M2) - Australia
Packaging & Transportation
Steel Frame
Packed on steel pallets to facilitate easy site unloading.
Weight Limit
Approximately 20 tons per 40'HQ shipping container.
Protection
Sandwich panels include protective films on both sides.
Design Inquiry Requirements
To provide an accurate quote, please provide: 1. Width / 2. Length / 3. Column Space / 4. Eave Height / 5. Wall Height (if any) / 6. Roof Slope / 7. Ventilation Needs / 8. Panel Materials / 9. Door & Window Sizes / 10. Crane Requirements (Capacity in Tons).
Frequently Asked Questions
What are the accepted payment terms?
Both TT and L/C are accepted. We prefer a 30% deposit before production and a 70% balance before loading by TT.
What is the typical delivery timeframe?
Delivery time depends on order quantities. Generally, it takes about 45 days after receiving the initial deposit.
How is the steel structure protected during shipping?
Steel frames are secured on pallets, and ends are wrapped with blankets or bubble plastic films. Sandwich panels are also packed specifically to prevent crashing during transit.
Do you offer on-site installation support?
Yes, we provide full Tekla model drawings and installation guides. For complex projects, we can send engineers or technical personnel to your site to guide the construction.
What is the durability of the steel structure?
Our steel structures are designed for a long service life, typically lasting up to 50 years with appropriate maintenance.
Can the structure withstand extreme weather?
Yes, our designs account for wind resistance up to 12 grades and earthquake resistance up to 8 grades, depending on your local requirements.
